INDUSTRIAL ANDROID TABLET
Model No：SF817
● Android 13, Cortex-A OCTA-CORE 2.0 GHz
● 8 Inch HD touch screen, Dual-band 2.4GHz / 5GHz
● Rugged IP66 Standard
● Large Battery Capacity 3.8V/9000mAh
● Honeywell &Zebra 1D/2D Barcode Reader for data collection
● Support UHF RFID &Fingerprint & infrared
● Communication with RJ45, RS232 for option
-
ANDROID 13
-
OCTA-CORE 2.0GHz
-
8 INCH DISPLAY
-
3.8v/9000mAh
-
UHF RFID
-
1D/2D BARCODE SCANNING
-
NFC SUPPORT 14443A protocol
-
4+64GB(6+128AS OPTION)
-
13MP Auto focus with flash
-
Support GPS,BEIDOU,GLONASS
-
PSAM security level under Protocol ISO7816
-
Fingerprint Identification (As Optional)
SF817- 8 Inch Industrial Tablet 8 is high performance terminal with Android 13.0 OS, Octa-core processor(4+64GB/6+128GB), 8 Inch HD capacitive screen, IP66 standard with powerful battery 9000mAh, 13MP camera, Built-in GPS, Beidou positioning and Glonass, and optional function of UHF & fingerprint sensor and infrared scanner, which widely applied in the industries of logistic, retail, transportation, financial and Sim card registration.
Super HD full Screen（1920*1200 high resolution）to offer wider viewing angles, readable under bright sunshine and usable with wet fingers, and maximize the satisfaction of consumer experience.
Up to 9000mAh, rechargeable and replaceable Large Lithium Battery which satisfy your needs of long time in outdoor.
Industrial IP66 protection standard，high strength industrial material, water and dust proof. Withstanding 1.2 meters drop without damage.
FBI certified fingerprint module as optional, comply with ISO19794-2/-4, ANSI378/381 and WSQ standard; making the authentication much safety and efficiency.
Efficient 1D and 2D barcode laser barcode scanner (Honeywell, Zebra or Newland) built-in to enable decoding different kinds of codes with high accuracy and high speed
NFC contactless card support, ISO 14443 Type A/B, Mifare card; High definition camera (5+13MP) making the shooting effect clearer and better,
High sensitive RFID UHF module as optional with high UHF tags reading.
Widely used for parking, ticket system, restaurant, retail store, supermarket, Census etc
Clothes wholesale
Supermarket
Express logistics
Smart power
Warehouse management
Health Care
Fingerprint recognition
Face recognition
| Product parameters | |
| Performance | |
| Octa core | |
| CPU | Octa-core 64-bit 2.0GHz high-performance processor |
| RAM+ROM | 4GB+64GB/6GB+128GB |
| System | Android 13.0 |
| Expand memory | Micro SD(TF) Supports up to 256GB |
| Data communication | |
| WLAN | Dual-band 2.4GHz / 5GHz,
Support IEEE 802.11ac/a/b/g/n/d/e/h/i/j/k/r/v protocol |
| WWAN | 2G：GSM（850/900/1800/1900MHz） |
| 3G：WCDMA（850/900/1900/2100MHz） | |
| 4G：FDD:B1/B3/B4/B7/B8/B12/B20
TDD:B38/B39/B40/B41 |
|
| Bluetooth | Support BT 5.0+BLE
Transmission distance 5-10 meters |
| GNSS | Support GPS, Beidou, Glonass, Galileo,AGPS, built-in antenna |
| Physical parameter | |
| Dimensions | 211.5 mm x 136.0 mm x 16.3 mm（The thinnest ） |
| Weight | ＜700g （Including batterry） |
| Display | 8 ” ,screen resolution 1280 x 800 |
| TP | Support multi-touch |
| Battery capacity | Rechargeable polymer battery (3.8V 9000 mAh) |
| Standby time >500 hours | |
| Working time > 10 hours(Depending on usage and network environment) | |
| Charging time 2-3hours,(with the standard source adapter and data cable) | |
| Expansion Card slot | SIM x 1,SIM/TF x1,PSAM x2(Optional) |
| Communication interface | Type-C USB x 1, OTG,USBA x2（Optional） |
| Audio | Speaker (mono), Microphone, Receiver |
| Keypad | Power key x1,Volume Side key x1,User set key x2 |
| Sensors | Gravity sensor, Gyroscope, Acceleration sensor |
| Language/input method | |
| Input | English, Pinyin,Handwriting input, Support soft keypad |
| Language | Chinese, English, Korean, Japanese, Malaysian,etc. |
| Data Collection | |
| Barcode scanning (Optional) | |
| Scanning engine | Honeywell N6703 N5703,6602 |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS,etc.
Postal Codes:USPS Planet, USPS Postnet, China Post, Korea Post, Australian Postal, Japan Postal, Dutch Postal (KIX), Royal Mail, Canadian Customs,etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, HanXi,etc. |
| Camera（Standard） | ||
| Rear camera | 13MP color camera/20MP color
camera(Optional) Support auto focus,Flash, Anti-shake, Macro shooting |
|
| Front camera | 5MP color camera | |
| UHF (Optional) | ||
| Frequency | 865-868 MHz((EHR) | |
| 902-928 MHz (USA) | ||
| 920-925 MHz (CHN)
Other multinational frequency standards (can be customized) |
||
| Protocol | EPC C1 GEN2 / ISO18000-6C | |
| Distance | 0—10m | |
| NFC (Optional） | ||
| Frequency | 13.56MHz | |
| Protocol | Support ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2 agreement | |
| Label standard | M1 card (S50, S70), CPU card, NFC label, etc | |
| Distance | 2-5cm | |
| ETC (Oprional) | ||
| Frequency | 5.7GHz-5.85GHz | |
| Protocol | Support GB/T 20851.1-2007 and GB/T 20851.2-2007 | |
| Distance | ≤7 m, power adjustable | |
| ID identification (Oprional) | ||
| Radio frequency technology | Comply with ISO/IEC 14443 type B standard, GA450-2003 General Technical Requirements for desktop ID card Reader, 1GA450-2003 General Technical Requirements for desktop ID Card Reader Amendment No. 1 (draft) | |
| Security module | Radio frequency technology | |
| Distance | 0-5cm | |
| Reading time | ＜1.55s | |
| Frequency | 13.5MHz±7kHz | |
| Fingerprint (Optional） | ||
| Frequency | Configure TCS semiconductor sensor with live identification technology | |
| Collection area | 11.3×12.4mm | |
| Resolution | 508 dpi, 8-bit grayscale | |
| Extraction format | ISO 19794, WSQ, ANSI 378, JPEG2000 | |
| Secure encryption | AES, DES key encryption for host communication channel | |
| Infrared (Optional) | ||
| Wavelength | 940nm | |
| Frequency | 38kHz | |
| Distance | ＞4m | |
| Protocol | DLT_645-2007,DLT_645-1997 | |
| User environment | ||
| Operating temperature | -20℃ – 55℃ | |
| Storage temperature | -40℃ – 70℃ | |
| Environment humidity | 5%RH–95%RH(no condensation) | |
| Drop specification | 6 sides Supports 1.2 meters drops on the marble within the operating temperature | |
| Sealing | IP66 | |
| Accessories | ||
| Standard | Adapter, Data cable, Protective film,
Instruction manual |
|
| Optional | Docking station:Communication interface RJ45x1、RS232x1、USBAx2 | |
-
